Key Features

• Rated Power: 6200VA / 6200W
• Surge Power: (Estimated) Around 12400VA
• Efficiency: 90%–93%
• Waveform: Pure Sine Wave
• Battery Voltage: 48VDC
• Solar Input Power: Up to 8000W
• MPPT Range: 60–450VDC
• Max Solar Charge Current: 120A
• Max AC Charge Current: 100A
• Max Combined Charge Current: 120A
• Overcharge Protection: 63VDC
• Communication: USB / RS232 / RS485 / WiFi / Dry Contact
• Dimensions: Approx. 119 × 313.6 × 457.5 mm
• Weight: Approx. 12 kg
• Operating Temp: -10°C to 50°C
• Humidity: 5% to 95% (Non-condensing)
